Desktop Spectrometer (CX9600)

The CX-9600 spectrometer can be used for quantitative element analysis and brand identification of solid metal samples. The optical system uses a CCD detector, and the spectral range covers all typical materials. The instrument is equipped with an argon flushing spark stand, and the open design spark stand is suitable for the analysis of samples of different shapes and sizes.

The CX-9600 spectrometer can be used for quantitative element analysis and brand identification of solid metal samples. The optical system uses a CCD detector, and the spectral range covers all typical materials. The instrument is equipped with an argon flushing spark stand, and the open design spark stand is suitable for the analysis of samples of different shapes and sizes.



Technical parameters of CX-9600 spectrometer:
Spectrometer optical system
• Paschen-Runge structure, Rowland circle optical system
• Rowland circle diameter: 350mm
• Effective wavelength range: 170 – 800 nm
• Detector: Multiple high-performance linear array CCDs
• Light chamber temperature: Automatically controlled constant temperature: 34℃±0.5℃
• Pixel resolution: 12pm
• Grating lines: 2400 l/mm
• Primary spectral line dispersion rate: 1.5 nm/mm
• External incident window for easy cleaning and replacement
• Excellent drift correction function-thanks to the automatic peak search function (accuracy reaches 0.1 pixel)
• Excellent UV band sensitivity, thanks to the new and improved vacuum technology



Application industries: foundry industry, wheel industry, mining machinery
